Description |
Honda Part Number |
Unit Price |
|
1: (34908-KW3-003) BULB,WEDGE BASE |
34908-GA7-701 |
Superceded |
|
1: (34908-KW3-003) BULB |
37102-567-009 |
Superceded |
|
1: (34908-KW3-003) BULB |
37237-SA5-003 |
Superceded |
|
1: (34908-KW3-003) BULB |
37237-SA5-004 |
Superceded |
|
2: (34908-MB0-003) BULB,WEDGE BASE |
34908-MB0-000 |
Superceded |
|
2: BULB,WEDGE BASE |
34908-MB0-003 |
|
|
2: (34908-MB0-003) BULB,WEDG BASE |
34908-MB0-005 |
Superceded |
|
3: METER, COMBINATION |
37100-MF5-671 |
Not Available |
|
4: CORD COMP.,PILOT |
37105-MF5-671 |
|
|
5: RUB,METER MOUNT |
37111-MF5-000 |
|
|
6: (37200-ME4-671) SPEEDOMETER ASSY. |
37200-MF5-671 |
Superceded |
|
7: COVER,SPEEDOMETER |
37202-ME8-008 |
Not Available |
|
8: CUSHION SPEEDMETE |
37204-ME8-008 |
|
|
9: MOUNT RUBBER BRKT |
37205-ME8-008 |
|
|
10: BRACKET A,METER |
37211-ME8-008 |
|
|
11: BRACKET B,METER |
37212-ME8-008 |
|
|
12: WASHER,PLAIN |
37244-MA6-008 |
|
|
13: TACHOMETER ASSY |
37250-MF5-611 |
|
|
13: (37250-MF5-611) TACHOMETER ASSY. |
37250-MF5-671 |
Superceded |
|
14: COVER,TACHOMETER |
37252-ME8-008 |
|
|
15: SOCKET TACHOMETER |
37253-ME8-008 |
|
|
16: CUSH.,TACHOMETER |
37254-ME8-008 |
|
|
17: (37260-MF5-010) CABLE,TACHOMETER |
37260-MF5-000 |
Superceded |
|
17: CABLE,TACHOMETER |
37260-MF5-010 |
|
|
18: CABLE,TACH INNER |
37261-425-000 |
|
|
19: COLLER B,TEMP MTR |
37314-ME8-000 |
Not Available |
|
20: COLLER A,TEMP MTR |
37315-ME8-000 |
Not Available |
|
21: (37450-ME8-018) METER ASSY.,TEMP |
37450-ME8-008 |
Superceded |
|
21: METER ASSY.,TEMPE |
37450-ME8-018 |
|
|
22: CUSH,TEMP METER |
37453-ME8-008 |
Not Available |
|
23: RUB.A,TEMP METER |
37454-ME8-008 |
Not Available |
|
24: RUB.B,TEMP METER |
37455-ME8-008 |
Not Available |
|
25: PLATE |
37456-ME8-008 |
Not Available |
|
26: (37600-MF5-672) BOX ASSY.,PILOT |
37600-MF5-671 |
Superceded |
|
26: BOX ASSY.,PILOT |
37600-MF5-672 |
|
|
27: CASE,PILOT UPPER |
37601-MF5-671 |
|
|
28: (37602-MF5-008) CASE,PILOT LOWER |
37602-ME8-671 |
Superceded |
|
29: LOW COV PILOT,BOX |
37617-ME8-008 |
|
|
30: CABLE ASSY,SPDMT |
44830-ME5-405 |
|
|
30: (44830-ME5-405) CABLE ASSY SPDMT. |
44830-ME5-850 |
Superceded |
|
30: (44830-ME5-405) CABLE,SPEEDOMETER |
44830-MF5-000 |
Superceded |
|
31: CABLE,INNER |
44831-KM1-000 |
|
|
31: (44831-KM1-000) CABLE,SPEDMT IN. |
44831-ME1-670 |
Superceded |
|
32: WASHER, PLAIN |
90104-ME8-000 |
Not Available |
|
33: SCREW,TAP.,4X45 |
90105-ME8-000 |
Not Available |
|
34: SCREW,TRUSS,4X16 |
90106-ME8-000 |
Not Available |
|
35: SCREW,TRUSS,4X35 |
90107-ME8-000 |
Not Available |
|
36: (94050-060-70) NUT,FLANGE,6MM |
90301-428-900 |
Superceded |
|
36: NUT,FLANGE,6MM |
94050-06070 |
|
|
37: WASHER, SPECIAL, 6MM |
90438-671-000 |
|
|
38: (91306-PJ4-000) ORING,6.8X1.9 |
91301-027-000 |
Superceded |
|
38: O RING, 6.8X1.9 |
91306-PJ4-000 |
|
|
38: (91306-PJ4-000) O-RING B,6.8X1.9 |
91310-MC7-003 |
Superceded |
|
39: SCREW,PAN,3X16 |
93500-03016-3J |
|
|
40: SCREW,CROSS,4X6 |
93500-04006-0A |
|
|
40: (93500-040-060A) PAN,SCREW 4X6 |
93500-04006-1A |
Superceded |
|
41: SCREW,CROSS,4X30 |
93500-04030-0A |
|
|
41: (93500-040-300A) SCREW,PAN,4X30 |
93500-04030-1A |
Superceded |
|
42: SCREW,PAN,5X25 |
93500-05025-0A |
|
|
43: SCREW,OVAL,5X20 |
93700-05020-0G |
|
|
44: TAPPING SCREW3X20 |
93901-22510 |
|
|
45: SCREW,TAPPING,4X16 |
93903-24480 |
|
|
46: NUT HEX.,4MM |
94002-04000-0S |
|
|
47: NUT,HEX.,6MM |
94002-06070-0S |
|
|
48: WASHER,4MM |
94101-04000 |
|
|
49: WASHER,SPG.,4MM |
94111-04000 |
|
|
